Container Specification
Sea Container Specification
| Equipment | Interior Dimensions | Door Opening | Top Opening | Tare Weight | Cubic Capacity | Payload* |
|---|---|---|---|---|---|---|
| 45′ High Cube Container |
L: 13.582 m 44′ 6 1/2″ W: 2.347 m 7’8.25″ H: 2.690 m 8’10” |
W: 2.347 m 7’8 1/4″ H: 2.584 m 8’5 3/4″ |
4,110 kg 9,061 lbs. |
85.7 cbm. 3,026 cu. ft. |
28,390 kg 62,589 lbs. |
|
| 40′ High Cube Container |
L: 12.056 m 39′ 6 1/2″ W: 2.347 m 7’8 1/4″ H: 2.684 m 8’9 1/2″ |
W: 2.340 m 7’8″ H: 2.585 m 8’5 3/4″ |
2,900 kg 6,393 lbs. |
76.0 cbm. 2,684 cu. ft. |
29,600 kg 65,256 lbs. |
|
| 40′ Dry Freight Container |
L: 12.051 m 39′ 6 1/2″ W: 2.340 m 7’8″ H: 2.380 m 7’9 1/2″ |
W: 2.286 m 7’6″ H: 2.278 m 7’5 1/2″ |
3,084 kg 6,799 lbs. 3,630 kg (steel) 8,003 lbs. (steel) |
67.3 cbm. 2,377 cu. ft. |
27,397 kg 60,401 lbs. |
|
| 20′ Dry Freight Container | L: 5.919 m 19′ 5″ W: 2.340 m 7’8″ H: 2.380 m 7’9 1/2″ |
W: 2.286 m 7’6″ H: 2.278 m 7’5 1/2″ |
1,900 kg 4,189 lbs. |
33.0 cbm. 1,165 cu. ft. |
22,100 kg 48,721 lbs. |
|
| 20′ Open Top Container |
L: 5.919 m 19′ 5″ W: 2.340 m 7’8″ H: 2.380 m 7’9 1/2″ |
W: 2.286 m 7’6″ H: 2.251 m 7’4 1/2″ |
L: 5.425 m 17’9 1/2″ W: 2.222 m 7’3 1/2″ |
2,174 kg 4,793 lbs. |
31.6 cbm. 1,116 cu. ft. |
21,826 kg 48,117 lbs. |
| 40′ Open Top Container |
L: 12.043 m 39′ 6″ W: 2.338 m 7’8″ H: 2.272 m 7’5 1/4″ |
W: 2.279 m 7’5 1/2″ H: 2.272 m 7’5 1/4″ |
L: 11.585 m 38′ W: 2.162 m 7’1″ |
4,300 kg 9,480 lbs. |
64.0 cbm. 2,260 cu. ft. |
26,181 kg 57,720 lbs. |
| 45′ High Cube Reefer Container |
L: 13.102 m 42’11 13/16″ W: 2.294 m 7’6 5/16″ H: 2.509 m 8’2 3/4″ |
W: 2.467 m 8’1 1/8″ H: 2.290 m 7’6 1/8″ |
5,200 kg 11,464 lbs. |
75.4 cbm. 2,663 cu. ft. |
28,350 kg 62,370 lbs. |
|
| 40′ High Cube Reefer Container |
L: 11.557 m 37’11” W: 2.286 m 7’6″ H: 2.491 m 8’2″ |
W: 2.286 m 7’6″ H: 2.454 m 8’1/2″ |
4,320 kg 9,524 lbs. |
65.8 cbm. 2,324 cu. ft. |
28,180 kg 62,126 lbs. |
|
| 40′ Reefer Container |
L: 11.207 m 36’9″ W: 2.246 m 7’4″ H: 2.183 m 7’2″ |
W: 2.216 m 7’3″ H: 2.183 m 7’2″ |
4,600 kg 10,141 lbs. |
54.9 cbm. 1,940 cu. ft. |
25,881 kg 57,059 lbs. |
|
| 20′ Flat Rack Container |
L: 5.702 m 18’8 1/2″ W: 2.438 m 8′ H: 2.327 m 7’7 1/2″ |
2,330 kg 5,137 lbs. |
21,670 kg 47,773 lbs. |
|||
| 40′ Flat Rack Container |
L: 11.820 m 38’9 1/4″ W: 2.148 m 7’6″ H: 2.095 m 6’10 1/2″ |
5,260 kg 11,596 lbs. |
25,220 kg 55,660 lbs. |
|||
| 40′ Artificial Tweendeck |
L: 12.065 m 39’7″ W: 2.216 m 7’3 1/4″ |
5,400 kg 11,905 lbs. |
39,000 kg 85,979 lbs. |
|||
| 40′ Collapsible Flat Rack |
L: 12.08 m 39’7 1/2″ W: 2.216 m 6’11 1/2″ H: 2.043 m 6’8 1/4″ |
5,800 kg 12,787 lbs. |
29,200 kg 64,374 lbs. |
Air Freight – Unit Load Devices
| ID code(IATA) | United States domestic code | Internal Volume | Limiting Internal Dimensions | * Maximum Gross Weight | ** Tare Weight |
|---|---|---|---|---|---|
| AQD,AMD | M-1 | 21.15 cu m 747 cu ft |
229x305x290/229cm 90x120x114/90in |
6,800kg 15,000lb |
340kg 750lb |
| AQA,AQ6,AMA | M-1 | 17.24 cu m 609 cuft |
229x305x229cm 90x120x90in |
6,800kg 15,000lb |
330kg 728lb |
| P6P,PMC | M-1 | 19.80 cu m 699 cu ft |
MD 6,800kg 15,000lb |
110kg 242lb |
|
| P1P,PAG,PAP,PAJ | M-1 | 17.97cu m 635 cu ft |
6,800kg 15,000lb |
110kg 242lb |
|
| P1P,PAG,PAP,PAJ | LD-7 | 11.10 cu m 392 cu ft |
4,626kg 10,200lb |
110kg 242lb |
|
| AA2,AAP | LD-9 | 10.39cu m 367 cu ft |
206x302x152cm 82x119x60in |
4,626kg 10,200lb |
200kg 440lb |
| AAU | LD-29 | 14.50 cu m 511 cu ft |
208x302x152cm 82x119x60in |
4,626kg 10,200lb |
260kg 573lb |
| DLF,DQF | LD-8 | 6.90 cu m 245 cu ft |
140x233x152cm 55x92x60in |
2,450kg 5,400lb |
128kg 282lb |
| AVA,AVE,AKE | LD-3 | 4.47 cu m 158 cu ft |
140x147x152cm 55x58x60in |
1,587kg 3,500lb |
77kg 170lb |
| AVC,AVJ,AKC | LD-1 | 4.84 cu m 171 cu ft |
140x147x152cm 53x58x60in |
1,587kg 3,500lb |
77kg 170lb |
